Since 1978, Hartmann Wheels has focused on bringing the highest quality wheels to the US market. Hartmann wheels are produced in a modern, state-of-the-art German owned foundry. Hartmann utilizes a low pressure casting process which produces a high performance wheel equal in strength and finish quality to OEM Audi and VW wheels. The wheels are heat treated for increased strength and are tested to JWL, VIA, and TUV standards.

Hartmann wheels are designed by Germany's finest engineers. The Hartmann HRS4-252-GS wheel is an OEM-inspired design featuring 7 split spokes which curve inwards to meet the centercap. The HRS4-252-GS wheels are finished with a gloss silver paint, and are designed to accept OEM lug bolts, OEM centercaps, and OEM TPMS senders.

Hartmann carefully selects their wheel offsets "ET"* to provide a fitment which will clear the brake caliper and suspension components, widen the track for better handling and aesthetics, and not allow the tire to contact the fender or fender liner during cornering or suspension travel, even on lowered vehicles. Fitment is backed by a money back guarantee.
*ET: from German "Einpresstiefe" (translates into "Insertion Depth") referred to as "Offset" in English: A measurement in mm of the distance between the center line of the wheel and the mounting surface of the wheel which contacts the hub face.

HARTMANN HRS4-252-GS FEATURES:

• Gloss Silver Finish
• Guaranteed fitment
• OE quality and strength
• Uses OEM R14 ball seat lug bolts
• Accepts OEM centercaps
• TPMS compatible
• Low pressure cast aluminum alloy
• Heat treated for high strength
• Tested to JWL, VIA, and TUV standards

HARTMANN HRS4-252-GS SPECIFICATIONS:

• Diameter: 22"
• Width: 9.5"
• Offset: ET50
• Bolt Pattern: 5x130
• Centerbore: 71.60 mm
• Centerbore Chamfer: 3 mm
• Lug Type: 14x1.5 R14 Ball Seat
• Centercap Audi: 4B0 601 170 A 7ZJ
• Load Rating: 900 Kg (1,984 Lbs)
• Weight: 17.06 Kg (37.6 Lbs) +/- .5 Kg

FITMENT GUIDE:
The Hartmann HRS4-252-GS wheel in 22x9.5" ET50 fits the following vehicles:

• 2007-2015 Audi Q7  ____________________  2007 Audi Q7  2008 Audi Q7  2009 Audi Q7  2010 Audi Q7  2011 Audi Q7  2012 Audi Q7  2013 Audi Q7  2014 Audi Q7  2015 Audi Q7
• 2005-2018 VW Touareg  ____________________  2005 VW Touareg  2006 VW Touareg  2007 VW Touareg  2008 VW Touareg  2009 VW Touareg  2010 VW Touareg  2011 VW Touareg  2012 VW Touareg  2013 VW Touareg  2014 VW Touareg  2015 VW Touareg  2016 VW Touareg  2017 VW Touareg  2018 VW Touareg
